Availability: | |
---|---|
High-temperature alloy mainly used for gas turbine, oil drilling, marine engineering, diesel engine, internal-combustion engine and the chemical industry as the high temperature machine parts, such as the turbine disk, turbine blade, condenser, overheating tube and some machine parts used under corrosion conditions.
High-temperature alloy mainly used for gas turbine, oil drilling, marine engineering, diesel engine, internal-combustion engine and the chemical industry as the high temperature machine parts, such as the turbine disk, turbine blade, condenser, overheating tube and some machine parts used under corrosion conditions.
New grade | UNS | W.Nr./EN | The original grade | Cr | Ni | W | Mo | Al | Ti | Fe |
GH1015 | GH15 | 19.0~22.0 | 34.0~39.0 | 4.8~5.8 | 2.5~3.2 | - | - | The remaining amount | 1.0~1.6 | |
GH1016 | GH16 | 19.0~22.0 | 32.0~36.0 | 5.0~6.0 | 2.6~3.3 | - | - | The remaining amount | 0.9~1.4 | |
GH1035 | GH35 | 20.0~23.0 | 35.0~40.0 | 2.5~3.5 | - | ≤0.50 | 0.7~1.2 | The remaining amount | 1.2~1.7 | |
GH1040 | GH40 | 15.0~17.0 | 24.0~27.0 | - | 5.5~7.0 | - | - | The remaining amount | - | |
GH1131 | GH131 | 19.0~22.0 | 25.0~30.0 | 4.8~6.0 | 2.8~3.5 | - | - | The remaining amount | 0.7~1.3 | |
GH1140 | GH140 | 20.0~23.0 | 35.0~40.0 | 1.4~1.8 | 2.0~2.5 | 0.2~0.6 | 0.7~1.2 | The remaining amount | - | |
GH2018 | GH18 | 18.0~21.0 | 40.0~44.0 | 1.8~2.2 | 3.7~4.3 | 0.35~0.75 | 1.8~2.0 | The remaining amount | - | |
GH2036 | GH36 | 11.5~13.5 | 7.0~9.0 | - | 1.1~1.4 | - | ≤0.12 | The remaining amount | 0.25~0.5 | |
G2038 | GH38A | 10.0~12.5 | 18.0~21.0 | - | - | ≤0.50 | 2.3~2.8 | The remaining amount | - | |
GH2130 | GH130 | 12.0~16.0 | 35.0~40.0 | 5.0~6.5 | - | 1.4~2.2 | 2.4~3.2 | The remaining amount | - | |
GH2132 | 660 | GH132 | 13.5~16.0 | 24.0~27.0 | - | 1.0~1.5 | ≤0.40 | 1.75~2.3 | The remaining amount | - |
GH2135 | GH135 | 14.0~16.0 | 33.0~36.0 | 1.7~2.2 | 1.7~2.2 | 2.0~2.8 | 2.1~2.5 | The remaining amount | - | |
GH2136 | GH136 | 13.0~16.0 | 24.5~28.5 | - | 1.0~1.75 | ≤0.35 | 2.4~3.2 | The remaining amount | - | |
GH2302 | GH302 | 12.0~16.0 | 38.0~42.0 | 3.5~4.5 | 1.5~2.5 | 1.8~2.3 | 2.3~2.8 | The remaining amount | - | |
GH3030 | 80Ni20Cr | GH30 | 19.0~22.0 | 74.3~77.5 | - | - | ≤0.15 | 0.15~0.35 | ≤1.5 | - |
GH3039 | GH39 | 19.0~22.0 | 68.5~74.9 | - | 1.8~2.3 | 0.35~0.75 | 0.35~0.75 | ≤3.0 | 0.19~1.3 | |
GH3044 | GH44 | 23.5~26.5 | 49.3~55.7 | 13.0~16.0 | ≤0.50 | ≤0.50 | 0.3~0.7 | ≤4.0 | - | |
GH3128 | GH128 | 19.0~22.0 | 54.9~61.7 | 7.5~9.0 | 7.5~9.0 | 0.4~0.8 | 0.4~0.8 | ≤2.0 | - | |
GH4033 | GH33 | 19.0~22.0 | 69.1~73.9 | - | - | 0.6~1.0 | 2.4~2.8 | ≤4.0 | - | |
GH4037 | GH37 | 3.0~26.0 | 71.8~72.9 | 5.0~7.0 | 2.0~4.0 | 1.7~2.3 | 1.8~2.3 | ≤5.0 | - | |
GH4043 | GH43 | 15.0~19.0 | 59.4~69.3 | 2.0~3.5 | 4.0~6.0 | 1.0~1.7 | 1.9~2.8 | ≤5.0 | 0.5~1.3 | |
GH4049 | GH49 | 9.5~11.0 | 52.9~59.0 | 5.0~6.0 | 4.5~5.5 | 3.7~4.4 | 1.4~1.9 | ≤1.5 | 注:Co(14~16) | |
GH4133 | GH33A | 19.0~22.0 | 74.0~76.0 | - | - | 0.7~1.2 | 2.5~3.0 | ≤1.50 | 1.15~1.65 | |
GH4169 | GH169 | 17.0~21.0 | 50.0~55.0 | - | 2.8~3.3 | 0.2~0.6 | 0.65~1.15 | The remaining amount | 4.75~5.5 |
New grade | UNS | W.Nr./EN | The original grade | Cr | Ni | W | Mo | Al | Ti | Fe |
GH1015 | GH15 | 19.0~22.0 | 34.0~39.0 | 4.8~5.8 | 2.5~3.2 | - | - | The remaining amount | 1.0~1.6 | |
GH1016 | GH16 | 19.0~22.0 | 32.0~36.0 | 5.0~6.0 | 2.6~3.3 | - | - | The remaining amount | 0.9~1.4 | |
GH1035 | GH35 | 20.0~23.0 | 35.0~40.0 | 2.5~3.5 | - | ≤0.50 | 0.7~1.2 | The remaining amount | 1.2~1.7 | |
GH1040 | GH40 | 15.0~17.0 | 24.0~27.0 | - | 5.5~7.0 | - | - | The remaining amount | - | |
GH1131 | GH131 | 19.0~22.0 | 25.0~30.0 | 4.8~6.0 | 2.8~3.5 | - | - | The remaining amount | 0.7~1.3 | |
GH1140 | GH140 | 20.0~23.0 | 35.0~40.0 | 1.4~1.8 | 2.0~2.5 | 0.2~0.6 | 0.7~1.2 | The remaining amount | - | |
GH2018 | GH18 | 18.0~21.0 | 40.0~44.0 | 1.8~2.2 | 3.7~4.3 | 0.35~0.75 | 1.8~2.0 | The remaining amount | - | |
GH2036 | GH36 | 11.5~13.5 | 7.0~9.0 | - | 1.1~1.4 | - | ≤0.12 | The remaining amount | 0.25~0.5 | |
G2038 | GH38A | 10.0~12.5 | 18.0~21.0 | - | - | ≤0.50 | 2.3~2.8 | The remaining amount | - | |
GH2130 | GH130 | 12.0~16.0 | 35.0~40.0 | 5.0~6.5 | - | 1.4~2.2 | 2.4~3.2 | The remaining amount | - | |
GH2132 | 660 | GH132 | 13.5~16.0 | 24.0~27.0 | - | 1.0~1.5 | ≤0.40 | 1.75~2.3 | The remaining amount | - |
GH2135 | GH135 | 14.0~16.0 | 33.0~36.0 | 1.7~2.2 | 1.7~2.2 | 2.0~2.8 | 2.1~2.5 | The remaining amount | - | |
GH2136 | GH136 | 13.0~16.0 | 24.5~28.5 | - | 1.0~1.75 | ≤0.35 | 2.4~3.2 | The remaining amount | - | |
GH2302 | GH302 | 12.0~16.0 | 38.0~42.0 | 3.5~4.5 | 1.5~2.5 | 1.8~2.3 | 2.3~2.8 | The remaining amount | - | |
GH3030 | 80Ni20Cr | GH30 | 19.0~22.0 | 74.3~77.5 | - | - | ≤0.15 | 0.15~0.35 | ≤1.5 | - |
GH3039 | GH39 | 19.0~22.0 | 68.5~74.9 | - | 1.8~2.3 | 0.35~0.75 | 0.35~0.75 | ≤3.0 | 0.19~1.3 | |
GH3044 | GH44 | 23.5~26.5 | 49.3~55.7 | 13.0~16.0 | ≤0.50 | ≤0.50 | 0.3~0.7 | ≤4.0 | - | |
GH3128 | GH128 | 19.0~22.0 | 54.9~61.7 | 7.5~9.0 | 7.5~9.0 | 0.4~0.8 | 0.4~0.8 | ≤2.0 | - | |
GH4033 | GH33 | 19.0~22.0 | 69.1~73.9 | - | - | 0.6~1.0 | 2.4~2.8 | ≤4.0 | - | |
GH4037 | GH37 | 3.0~26.0 | 71.8~72.9 | 5.0~7.0 | 2.0~4.0 | 1.7~2.3 | 1.8~2.3 | ≤5.0 | - | |
GH4043 | GH43 | 15.0~19.0 | 59.4~69.3 | 2.0~3.5 | 4.0~6.0 | 1.0~1.7 | 1.9~2.8 | ≤5.0 | 0.5~1.3 | |
GH4049 | GH49 | 9.5~11.0 | 52.9~59.0 | 5.0~6.0 | 4.5~5.5 | 3.7~4.4 | 1.4~1.9 | ≤1.5 | 注:Co(14~16) | |
GH4133 | GH33A | 19.0~22.0 | 74.0~76.0 | - | - | 0.7~1.2 | 2.5~3.0 | ≤1.50 | 1.15~1.65 | |
GH4169 | GH169 | 17.0~21.0 | 50.0~55.0 | - | 2.8~3.3 | 0.2~0.6 | 0.65~1.15 | The remaining amount | 4.75~5.5 |
Packing:
All Wenzhou Taixin Steel's products are packed, stored, transported according to the international regulation. The products are wrapped with anti-rust paper and steel rings to prevent damage. Identification labels are tagged according to standard specification or customer's instructions. Special packing is available as per customer's requirement.Ply wooden box are available for special protection. Other kinds of packing can be offered if request.
Packing:
All Wenzhou Taixin Steel's products are packed, stored, transported according to the international regulation. The products are wrapped with anti-rust paper and steel rings to prevent damage. Identification labels are tagged according to standard specification or customer's instructions. Special packing is available as per customer's requirement.Ply wooden box are available for special protection. Other kinds of packing can be offered if request.
