Alloy 904L is an austenitic stainless steel intended for use under severe corrosion conditions, with a very good resistance to attacks in acidic environment, as sulphuric, phosphoric and acetic acid. Very good resistance to pitting corrosion, stress corrosion cracking and a much better resistance to crevice corrosion than steels of alloy 304L and alloy 316L. Used for chemical processing, pollution control equipment, oil and gas well piping, heat exchangers, acid production and pickling equipment.
Standard: AISI, ASTM, DIN, EN, GB and JIS
Outer Diameter: 1mm-1500mm
Thickness: 0.1mm-50mm
Length: 1-12m
Surface: Annealed/Pickling/Polished
Shape: Round/Square/Hex
Technique: Hot Rolled/Cold Drawn
Alloy 904L is an austenitic stainless steel intended for use under severe corrosion conditions, with a very good resistance to attacks in acidic environment, as sulphuric, phosphoric and acetic acid. Very good resistance to pitting corrosion, stress corrosion cracking and a much better resistance to crevice corrosion than steels of alloy 304L and alloy 316L. Used for chemical processing, pollution control equipment, oil and gas well piping, heat exchangers, acid production and pickling equipment.
Standard: AISI, ASTM, DIN, EN, GB and JIS
Outer Diameter: 1mm-1500mm
Thickness: 0.1mm-50mm
Length: 1-12m
Surface: Annealed/Pickling/Polished
Shape: Round/Square/Hex
Technique: Hot Rolled/Cold Drawn
AISI/ASTM | UNS | ID | W.Nr | ||
904L | N08904 | F904L | 1.4539 | ||
Chemical Composition: | |||||
Grade | % | Ni | Cr | Mo | Cu |
904L | Min | 23 | 19 | 4 | 1 |
Max | 28 | 23 | 5 | 2 | |
Si | C | Mn | P | S | |
Min | - | - | - | ||
Max | 1 | 0.02 | 2 | 0.04 | 0.03 |
Physical Performance: | |||||
Density | 8.0 g/cm3 | ||||
Melting point | 1300-1390 | ||||
Grade | T*S | Y*S | El | ||
Rm N/mm2 | RP0.2N/mm2 | A5 % | |||
904L | 490 | 215 | 35 |
AISI/ASTM | UNS | ID | W.Nr | ||
904L | N08904 | F904L | 1.4539 | ||
Chemical Composition: | |||||
Grade | % | Ni | Cr | Mo | Cu |
904L | Min | 23 | 19 | 4 | 1 |
Max | 28 | 23 | 5 | 2 | |
Si | C | Mn | P | S | |
Min | - | - | - | ||
Max | 1 | 0.02 | 2 | 0.04 | 0.03 |
Physical Performance: | |||||
Density | 8.0 g/cm3 | ||||
Melting point | 1300-1390 | ||||
Grade | T*S | Y*S | El | ||
Rm N/mm2 | RP0.2N/mm2 | A5 % | |||
904L | 490 | 215 | 35 |
With plastic cap to protect both ends
Plastic bag wrapped outside pipe
Woven bag wrapped outside pipe
All our products are packed, stored, transported according to the international regulation.
The tubes are wrapped with anti-rust paper and steel rings to prevent damage. Identification labels are tagged according to standard specification or customer's instructions. Special packing is available as per customer's requirement.
Plus, ply wooden box are available for special protection. Other kinds of packing can be offered if request.
With plastic cap to protect both ends
Plastic bag wrapped outside pipe
Woven bag wrapped outside pipe
All our products are packed, stored, transported according to the international regulation.
The tubes are wrapped with anti-rust paper and steel rings to prevent damage. Identification labels are tagged according to standard specification or customer's instructions. Special packing is available as per customer's requirement.
Plus, ply wooden box are available for special protection. Other kinds of packing can be offered if request.
