Availability: | |
---|---|
Tolerance:
Thickness and tolerances(+/-)in mm | |||||||||||||||
Nominal thickness | width<125mm | 125<width<250 | 250<width<1250 | ||||||||||||
> | < | Standard | Fine | Precision | Standard | Fine | Precision | Standard | Fine | Precision | |||||
0.4 | 0.5 | 0.025 | 0.02 | 0.012 | 0.03 | 0.02 | 0.015 | 0.035 | 0.025 | 0.018 | |||||
0.5 | 0.6 | 0.03 | 0.02 | 0.012 | 0.03 | 0.025 | 0.015 | 0.04 | 0.03 | 0.02 | |||||
0.6 | 0.8 | 0.03 | 0.025 | 0.015 | 0.035 | 0.03 | 0.018 | 0.04 | 0.035 | 0.025 | |||||
0.8 | 1 | 0.03 | 0.025 | 0.015 | 0.04 | 0.03 | 0.02 | 0.05 | 0.035 | 0.025 | |||||
1 | 1.25 | 0.035 | 0.03 | 0.02 | 0.045 | 0.035 | 0.025 | 0.05 | 0.04 | 0.03 | |||||
1.25 | 1.5 | 0.04 | 0.03 | 0.02 | 0.05 | 0.035 | 0.025 | 0.06 | 0.045 | 0.03 |
Grade:
Grade and Main chemical composition% | |||||||||
C | Si | Mn | P≤ | S≤ | Cr | Mo | Ni | Other | |
201 | ≤0.15 | ≤1.00 | 5.5-7.5 | 0.06 | 0.03 | 16-18 | - | 3.5-5.5 | N≤0.25 |
202 | ≤0.15 | ≤1.00 | 7.5-10.0 | 0.06 | 0.03 | 17-19 | - | 4.0-6.0 | N≤0.25 |
301 | ≤0.15 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 16-18 | - | 6.0-8.0 | - |
302 | ≤0.15 | ≤1.00 | ≤2.00 | 0.2 | 0.03 | 17-19 | - | 8-10.0 | - |
303 | ≤0.15 | ≤1.00 | ≤2.00 | 0.045 | ≥0.015 | 17-19 | ≤0.6 | 8.0-10.0 | - |
304 | ≤0.08 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 18-20 | - | 8-10.5 | - |
304L | ≤0.03 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 18-20 | - | 9-13 | - |
305 | ≤0.12 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 17-19 | - | 10.5-13 | - |
309S | ≤0.08 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 22-24 | - | 12-15 | - |
310S | ≤0.08 | ≤1.5 | ≤2.00 | 0.045 | 0.03 | 24-26 | - | 19-22 | - |
316 | ≤0.08 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 16-18 | 2-3 | 10-14 | - |
316L | ≤0.03 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 16-18 | 2-3 | 12-15 | - |
317 | ≤0.08 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 18-20 | 3-4 | 11-15 | - |
317L | ≤0.03 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 18-20 | 3-4 | 11-15 | - |
321 | ≤0.08 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 17-19 | - | 9-13 | Ti≥5×C |
405 | ≤0.08 | ≤1.00 | ≤1.00 | 0.04 | 0.03 | 11.5-14.5 | - | ≤0.6 | AL0.1-0.3 |
420F | 0.26-0.4 | ≤1.00 | ≤1.25 | 0.06 | ≥0.15 | 12-14 | ≤0.6 | ≤0.6 | - |
430 | ≤0.12 | ≤0.75 | ≤1.00 | 0.04 | 0.03 | 16-18 | - | ≤0.6 |
Tolerance:
Thickness and tolerances(+/-)in mm | |||||||||||||||
Nominal thickness | width<125mm | 125<width<250 | 250<width<1250 | ||||||||||||
> | < | Standard | Fine | Precision | Standard | Fine | Precision | Standard | Fine | Precision | |||||
0.4 | 0.5 | 0.025 | 0.02 | 0.012 | 0.03 | 0.02 | 0.015 | 0.035 | 0.025 | 0.018 | |||||
0.5 | 0.6 | 0.03 | 0.02 | 0.012 | 0.03 | 0.025 | 0.015 | 0.04 | 0.03 | 0.02 | |||||
0.6 | 0.8 | 0.03 | 0.025 | 0.015 | 0.035 | 0.03 | 0.018 | 0.04 | 0.035 | 0.025 | |||||
0.8 | 1 | 0.03 | 0.025 | 0.015 | 0.04 | 0.03 | 0.02 | 0.05 | 0.035 | 0.025 | |||||
1 | 1.25 | 0.035 | 0.03 | 0.02 | 0.045 | 0.035 | 0.025 | 0.05 | 0.04 | 0.03 | |||||
1.25 | 1.5 | 0.04 | 0.03 | 0.02 | 0.05 | 0.035 | 0.025 | 0.06 | 0.045 | 0.03 |
Grade:
Grade and Main chemical composition% | |||||||||
C | Si | Mn | P≤ | S≤ | Cr | Mo | Ni | Other | |
201 | ≤0.15 | ≤1.00 | 5.5-7.5 | 0.06 | 0.03 | 16-18 | - | 3.5-5.5 | N≤0.25 |
202 | ≤0.15 | ≤1.00 | 7.5-10.0 | 0.06 | 0.03 | 17-19 | - | 4.0-6.0 | N≤0.25 |
301 | ≤0.15 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 16-18 | - | 6.0-8.0 | - |
302 | ≤0.15 | ≤1.00 | ≤2.00 | 0.2 | 0.03 | 17-19 | - | 8-10.0 | - |
303 | ≤0.15 | ≤1.00 | ≤2.00 | 0.045 | ≥0.015 | 17-19 | ≤0.6 | 8.0-10.0 | - |
304 | ≤0.08 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 18-20 | - | 8-10.5 | - |
304L | ≤0.03 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 18-20 | - | 9-13 | - |
305 | ≤0.12 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 17-19 | - | 10.5-13 | - |
309S | ≤0.08 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 22-24 | - | 12-15 | - |
310S | ≤0.08 | ≤1.5 | ≤2.00 | 0.045 | 0.03 | 24-26 | - | 19-22 | - |
316 | ≤0.08 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 16-18 | 2-3 | 10-14 | - |
316L | ≤0.03 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 16-18 | 2-3 | 12-15 | - |
317 | ≤0.08 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 18-20 | 3-4 | 11-15 | - |
317L | ≤0.03 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 18-20 | 3-4 | 11-15 | - |
321 | ≤0.08 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 17-19 | - | 9-13 | Ti≥5×C |
405 | ≤0.08 | ≤1.00 | ≤1.00 | 0.04 | 0.03 | 11.5-14.5 | - | ≤0.6 | AL0.1-0.3 |
420F | 0.26-0.4 | ≤1.00 | ≤1.25 | 0.06 | ≥0.15 | 12-14 | ≤0.6 | ≤0.6 | - |
430 | ≤0.12 | ≤0.75 | ≤1.00 | 0.04 | 0.03 | 16-18 | - | ≤0.6 |
Specification:
We pride ourselves in excellent quality products with competitive pricing and prompt delivery.
Specifications of Stainless Steel Precision Strip:
Materials:
300series:301,302,303,304,304L,309,309s,310,310S,316,316L,316Ti,317L,321,347,
200series:201,202,202cu,204;
400series:409,409L,410,420,430,431,440;
Others:2205,2507,2906,330,660,630,631,17-4ph,17-7 ph,904L,etc
Standard:
ASTM A240,JIS G4304, G4305,GB/T 4237,GB/T 8165
Thickness:
0.01mm~0.5mm
Thickness Tolerance:
thickness≤0.1mm ±2.5μm thickness≤0.5mm ±5μm
Width: 2.0mm~650mm
Width Tolerance: width≤30mm ±0.015mm width≤100mm ±0.03mm width≤250mm ±0.055mm width≤610mm ±0.1mm
Surface finish: 2B, BA, etc
Straight: Minimum 3IU
Edge situation, Bur: thickness 0.02 ~0.1mm≤6% thickness0.1 ~0.5mm≤5%
Specification:
We pride ourselves in excellent quality products with competitive pricing and prompt delivery.
Specifications of Stainless Steel Precision Strip:
Materials:
300series:301,302,303,304,304L,309,309s,310,310S,316,316L,316Ti,317L,321,347,
200series:201,202,202cu,204;
400series:409,409L,410,420,430,431,440;
Others:2205,2507,2906,330,660,630,631,17-4ph,17-7 ph,904L,etc
Standard:
ASTM A240,JIS G4304, G4305,GB/T 4237,GB/T 8165
Thickness:
0.01mm~0.5mm
Thickness Tolerance:
thickness≤0.1mm ±2.5μm thickness≤0.5mm ±5μm
Width: 2.0mm~650mm
Width Tolerance: width≤30mm ±0.015mm width≤100mm ±0.03mm width≤250mm ±0.055mm width≤610mm ±0.1mm
Surface finish: 2B, BA, etc
Straight: Minimum 3IU
Edge situation, Bur: thickness 0.02 ~0.1mm≤6% thickness0.1 ~0.5mm≤5%
All our products are packed, stored, transported according to the international regulation.
The products are wrapped with anti-rust paper and steel rings to prevent damage. Identification labels are tagged according to standard specification or customer's instructions. Special packing is available as per customer's requirement.Ply wooden box are available for special protection. Other kinds of packing can be offered if request.
All our products are packed, stored, transported according to the international regulation.
The products are wrapped with anti-rust paper and steel rings to prevent damage. Identification labels are tagged according to standard specification or customer's instructions. Special packing is available as per customer's requirement.Ply wooden box are available for special protection. Other kinds of packing can be offered if request.
