Availability: | |
---|---|
Standard: ASTM, AISI, JIS, GB ,SUS
Thickness: 0.2mm~150mm
Width: 40-2000mm or as your requirement
Length: 2000-11000mm or as your requirement
Technique: hot rolled: 3~150mm thickness
cold rolled: 0.2~6mm thickness
Surface:
2B, BA, No.4,HL,No.1 ,etc
Standard: ASTM, AISI, JIS, GB ,SUS
Thickness: 0.2mm~150mm
Width: 40-2000mm or as your requirement
Length: 2000-11000mm or as your requirement
Technique: hot rolled: 3~150mm thickness
cold rolled: 0.2~6mm thickness
Surface:
2B, BA, No.4,HL,No.1 ,etc
Chemical Composition Limits | ||||||||
WT % | C | Mn | P | S | Si | Cr | Ni | other |
304L | 0.03 | 2 | 0.045 | 0.03 | 1 | 18 - 20 | 8-12 | --- |
Physical Properties | Metric | English | Comments |
Density | 8 g/cc | 0.289 lb/in³ |
Mechanical Properties | |||
Hardness, Knoop | 158 | 158 | Converted from Rockwell B Hardness Value |
Hardness, Rockwell B | 82 | 82 | |
Hardness, Rockwell C | 15 | 15 | 10% Cold-worked |
Hardness, Vickers | 159 | 159 | Converted from Rockwell B Hardness Value. |
Tensile Strength, Ultimate | 564 MPa | 81800 psi | 0% Cold-worked |
Tensile Strength, Yield | 210 MPa | 30500 psi | 0% Cold-worked |
Elongation at Break | 58 % | 58 % | In 50mm (2 in.) |
Modulus of Elasticity | 193 - 200 GPa | 28000 - 29000 ksi | |
Charpy Impact | 216 J | 159 ft-lb |
Chemical Composition Limits | ||||||||
WT % | C | Mn | P | S | Si | Cr | Ni | other |
304L | 0.03 | 2 | 0.045 | 0.03 | 1 | 18 - 20 | 8-12 | --- |
Physical Properties | Metric | English | Comments |
Density | 8 g/cc | 0.289 lb/in³ |
Mechanical Properties | |||
Hardness, Knoop | 158 | 158 | Converted from Rockwell B Hardness Value |
Hardness, Rockwell B | 82 | 82 | |
Hardness, Rockwell C | 15 | 15 | 10% Cold-worked |
Hardness, Vickers | 159 | 159 | Converted from Rockwell B Hardness Value. |
Tensile Strength, Ultimate | 564 MPa | 81800 psi | 0% Cold-worked |
Tensile Strength, Yield | 210 MPa | 30500 psi | 0% Cold-worked |
Elongation at Break | 58 % | 58 % | In 50mm (2 in.) |
Modulus of Elasticity | 193 - 200 GPa | 28000 - 29000 ksi | |
Charpy Impact | 216 J | 159 ft-lb |
Protected by PVC and PE cover.packed and labeled according to the regulations and customer's requests.Great care is taken to avoid any damage which might otherwise be caused during storage or transportation. In addition, clear labels are tagged on the outside of the packages for easy identification of the product I. D. and quality information.
Protected by PVC and PE cover.packed and labeled according to the regulations and customer's requests.Great care is taken to avoid any damage which might otherwise be caused during storage or transportation. In addition, clear labels are tagged on the outside of the packages for easy identification of the product I. D. and quality information.
