Availability: | |
---|---|
Chemical Composition:
Grade | % | Ni | Cr | Fe | Nb | Co | C |
InconelX-750 | Min | Rest | 14 | 5 | 0.7 | ||
Max | 17 | 9 | 1.2 | 1 | 0.08 | ||
Mn | Si | S | Cu | Al | Ti | P | |
0.4 | 2.25 | ||||||
1 | 0.5 | 0.01 | 0.5 | 1 | 2.75 | 0.02 |
Physical Performance:
Density | 8.25 g/cm³ | |||
Smelt Point | 1395-1425 | |||
H*T | T*S | Y*S | El | Hardness |
Rm N/mm2 | RP0.2N/mm2 | A5 % | HB | |
Solution | 910 | 550 | 25 | ≤350 |
Chemical Composition:
Grade | % | Ni | Cr | Fe | Nb | Co | C |
InconelX-750 | Min | Rest | 14 | 5 | 0.7 | ||
Max | 17 | 9 | 1.2 | 1 | 0.08 | ||
Mn | Si | S | Cu | Al | Ti | P | |
0.4 | 2.25 | ||||||
1 | 0.5 | 0.01 | 0.5 | 1 | 2.75 | 0.02 |
Physical Performance:
Density | 8.25 g/cm³ | |||
Smelt Point | 1395-1425 | |||
H*T | T*S | Y*S | El | Hardness |
Rm N/mm2 | RP0.2N/mm2 | A5 % | HB | |
Solution | 910 | 550 | 25 | ≤350 |
Standard of execution:
Form | ASTM |
Rod | B 574 |
Plate, sheet and strip | B 575 |
Seamless pipe and tube | B 622 |
Welded pipe | B 619, B 775 |
Welded tube | B 626, B 751 |
Welding fitting | B 366 |
Forged or rolled pipe flange and forged fitting | B 462 |
Billet and bar for reforging | B 472 |
Forging | B 564 |
Standard of execution:
Form | ASTM |
Rod | B 574 |
Plate, sheet and strip | B 575 |
Seamless pipe and tube | B 622 |
Welded pipe | B 619, B 775 |
Welded tube | B 626, B 751 |
Welding fitting | B 366 |
Forged or rolled pipe flange and forged fitting | B 462 |
Billet and bar for reforging | B 472 |
Forging | B 564 |
Inconel X-750 Characteristic as below:
Inconel X-750 is a precipitation-hardenable alloy which has been used in applications such as high temperature structural members for gas turbines, jet engine parts, nuclear power plant applications, heat-treating fixtures, forming tools, and extrusion dies. The alloy is highly resistant to chemical corrosion and oxidation and has high stress-rupture strength and low creep rates under high stresses at temperatures up to 1500°F (816°C) after suitable heat treatment.
Inconel X-750 Corrosion resistance:
Inconel X-750 has excellent resistance to chloride ion stress-corrosion cracking. It exhibits satisfactory resistance to numerous oxidizing environments. The alloy has similar corrosion resistance to alloy 600 in many media.
Incoloy X-750 Application range and field:
Nuclear reactors
Gas turbines
Rocket engines
Pressure vessels
Inconel X-750 Machinability:
Conventional machining techniques used for iron based alloys may be used. This alloy does work-harden during machining and has higher strength and "gumminess" not typical of steels. Heavy duty machining equipment and tooling should be used to minimize chatter or work-hardening of the alloy ahead of the cutting.
Inconel X-750 Characteristic as below:
Inconel X-750 is a precipitation-hardenable alloy which has been used in applications such as high temperature structural members for gas turbines, jet engine parts, nuclear power plant applications, heat-treating fixtures, forming tools, and extrusion dies. The alloy is highly resistant to chemical corrosion and oxidation and has high stress-rupture strength and low creep rates under high stresses at temperatures up to 1500°F (816°C) after suitable heat treatment.
Inconel X-750 Corrosion resistance:
Inconel X-750 has excellent resistance to chloride ion stress-corrosion cracking. It exhibits satisfactory resistance to numerous oxidizing environments. The alloy has similar corrosion resistance to alloy 600 in many media.
Incoloy X-750 Application range and field:
Nuclear reactors
Gas turbines
Rocket engines
Pressure vessels
Inconel X-750 Machinability:
Conventional machining techniques used for iron based alloys may be used. This alloy does work-harden during machining and has higher strength and "gumminess" not typical of steels. Heavy duty machining equipment and tooling should be used to minimize chatter or work-hardening of the alloy ahead of the cutting.
