Chemical Composition
Grade | % | Ni | Cr | Mo | W | Fe |
Hastelloy X | Min | Rest | 20.5 | 8 | 0.2 | 17 |
Max | 23 | 10 | 1 | 22 | ||
Mn | C | Si | S | P | Co | |
- | 0.05 | - | - | - | 0.5 | |
1 | 0.15 | 1 | 0.03 | 0.04 | 2.5 |
Physical Performance
Density | 8.94 g/cm3 | ||
Smelt | 1260-1355 | ||
Heat | T*S | Y*S | El |
Rm N/mm2 | RP0.2N/mm2 | A5 % | |
Hastelloy | 660 | 240 | 35 |
Chemical Composition
Grade | % | Ni | Cr | Mo | W | Fe |
Hastelloy X | Min | Rest | 20.5 | 8 | 0.2 | 17 |
Max | 23 | 10 | 1 | 22 | ||
Mn | C | Si | S | P | Co | |
- | 0.05 | - | - | - | 0.5 | |
1 | 0.15 | 1 | 0.03 | 0.04 | 2.5 |
Physical Performance
Density | 8.94 g/cm3 | ||
Smelt | 1260-1355 | ||
Heat | T*S | Y*S | El |
Rm N/mm2 | RP0.2N/mm2 | A5 % | |
Hastelloy | 660 | 240 | 35 |
Standard of execution:
Form | ASTM |
Rod | B 574 |
Plate, sheet and strip | B 575 |
Seamless pipe and tube | B 622 |
Welded pipe | B 619, B 775 |
Welded tube | B 626, B 751 |
Welding fitting | B 366 |
Forged or rolled pipe flange and forged fitting | B 462 |
Billet and bar for reforging | B 472 |
Forging | B 564 |
Standard of execution:
Form | ASTM |
Rod | B 574 |
Plate, sheet and strip | B 575 |
Seamless pipe and tube | B 622 |
Welded pipe | B 619, B 775 |
Welded tube | B 626, B 751 |
Welding fitting | B 366 |
Forged or rolled pipe flange and forged fitting | B 462 |
Billet and bar for reforging | B 472 |
Forging | B 564 |
Characteristics of Hastelloy X:
Outstanding oxidation resistance through 2000° F
Resistant to carburization and nitriding
Excellent high temperature strength
Good resistance to chloride stress-corrosion cracking
Applications is Hastelloy X :
Gas turbines
Petrochemical industry
Industrial furnaces
Heat treating equipment
Nuclear engineering
Jet engine combustion chambers
Aircraft cabin heaters
Turbine exhaust components
In what forms is Hastelloy X Available at Taixin?
Sheet
Plate
Bar
Characteristics of Hastelloy X:
Outstanding oxidation resistance through 2000° F
Resistant to carburization and nitriding
Excellent high temperature strength
Good resistance to chloride stress-corrosion cracking
Applications is Hastelloy X :
Gas turbines
Petrochemical industry
Industrial furnaces
Heat treating equipment
Nuclear engineering
Jet engine combustion chambers
Aircraft cabin heaters
Turbine exhaust components
In what forms is Hastelloy X Available at Taixin?
Sheet
Plate
Bar
