Availability: | |
---|---|
Chemical Composition:
Chemical Composition Limits | |||||||||||||
Weight % | Ni | Cr | Ti | Al | C | Si | Cu | Fe | Mn | Co | B | Zr | S |
Alloy 80A | Bal | 18.0-21.0 | 1.8-2.7 | 1.0-1.8 | 0.10 max | 1.0 max | 0.2 max | 3.0 max | 1.0 max | 2.0 max | 0.008 max | 0.15 max | 0.015 max |
Typical Mechanical Properties:
Material | Condition | Ultimate Tensile Strength ksi | Yield Strength ksi | Elongation on 4D (min) | Hardness min |
Alloy 80A | Solution Annealed & Precipatation Treated (aged) | 145 | 90 | 20 | 300 HV |
Chemical Composition:
Chemical Composition Limits | |||||||||||||
Weight % | Ni | Cr | Ti | Al | C | Si | Cu | Fe | Mn | Co | B | Zr | S |
Alloy 80A | Bal | 18.0-21.0 | 1.8-2.7 | 1.0-1.8 | 0.10 max | 1.0 max | 0.2 max | 3.0 max | 1.0 max | 2.0 max | 0.008 max | 0.15 max | 0.015 max |
Typical Mechanical Properties:
Material | Condition | Ultimate Tensile Strength ksi | Yield Strength ksi | Elongation on 4D (min) | Hardness min |
Alloy 80A | Solution Annealed & Precipatation Treated (aged) | 145 | 90 | 20 | 300 HV |
Standard of execution:
Form | ASTM |
Rod | B 574 |
Plate, sheet and strip | B 575 |
Seamless pipe and tube | B 622 |
Welded pipe | B 619, B 775 |
Welded tube | B 626, B 751 |
Welding fitting | B 366 |
Forged or rolled pipe flange and forged fitting | B 462 |
Billet and bar for reforging | B 472 |
Forging | B 564 |
Standard of execution:
Form | ASTM |
Rod | B 574 |
Plate, sheet and strip | B 575 |
Seamless pipe and tube | B 622 |
Welded pipe | B 619, B 775 |
Welded tube | B 626, B 751 |
Welding fitting | B 366 |
Forged or rolled pipe flange and forged fitting | B 462 |
Billet and bar for reforging | B 472 |
Forging | B 564 |
The NIMONIC alloy 80A is used in the following applications:
Gas turbine engineering
Automobile exhaust valves
Die-casting inserts and cores
Nuclear boiler tube parts.
Packing:
All Wenzhou Taixin Stainless Steel's products are packed, stored, transported according to the international regulation. The products are wrapped with anti-rust paper and steel rings to prevent damage. Identification labels are tagged according to standard specification or customer's instructions. Special packing is available as per customer's requirement.Ply wooden box are available for special protection. Other kinds of packing can be offered if request.
The NIMONIC alloy 80A is used in the following applications:
Gas turbine engineering
Automobile exhaust valves
Die-casting inserts and cores
Nuclear boiler tube parts.
Packing:
All Wenzhou Taixin Stainless Steel's products are packed, stored, transported according to the international regulation. The products are wrapped with anti-rust paper and steel rings to prevent damage. Identification labels are tagged according to standard specification or customer's instructions. Special packing is available as per customer's requirement.Ply wooden box are available for special protection. Other kinds of packing can be offered if request.
