Annealed Stainless Steel Soft Wire

Grade: ASTM: 201, 202, 204Cu, 301, 302, 303, 304, 304Cu, 304HC, 304L, 304H, 310, 310S, 312, 314, 316, 316L, 316LN, 316Ti, 316LCu, 321, 410, 420, 430, 430L

Availability:



Inquire

1) Grade: ASTM: 201, 202, 204Cu, 301, 302, 303, 304, 304Cu, 304HC, 304L, 304H, 310, 310S, 312, 314, 316, 316L, 316LN, 316Ti, 316LCu, 321, 410, 420, 430, 430L
DIN/EN:1.4301, 1.4306, 1.4307, 1.4310, 1.4401, 1.4404, 1.4567, 1.4841, 1.4842, 1.4541, 1.4845, 1.4570, 1.4571, 1.4578, 1.4597, 1.4362, 1.4370, 1.4016
2) Standard: GB,SUS,ASTM,AISI, EN,DIN,JIS,BS – also to other equivalent international standards.
3) Diameter: 0.01-25mm
4) Surface: bright, cloudy, plain, black
5) Condition: soft wire, semi-soft wire, hard wire
6) Type: Hydrogen, Cold-drawn, Cold heading, Annealed
7) Packing: in coil, bundle or spool then in carton, or as your request

SWG & BWG of annealed stainless steel soft wire

SWG (MM )	BWG (MM )			SWG (MM)	BWG (MM)			SWG (MM )	BWG (MM )
0	8.230	8.636	0.340	17	1.422	1.473	0.058	34	0.234	0.178	0.007
1	7.620	7.620	0.300	18	1.219	1.245	0.049	35	0.213	0.127	0.005
2	7.010	7.214	0.284	19	1.016	1.067	0.042	36	0.193	0.102	0.004
3	6.401	6.579	0.259	20	0.914	0.889	0.035	37	0.173	*	0.0068
4	5.893	6.045	0.238	21	0.813	0.813	0.032	38	0.152	*	0.0060
5	5.385	5.588	0.220	22	0.711	0.711	0.028	39	0.132	*	0.0052
6	4.877	5.156	0.203	23	0.610	0.635	0.025	40	0.122	*	0.0048
7	4.470	4.572	0.180	24	0.559	0.559	0.022	41	0.112	*	0.0044
8	4.064	4.191	0.165	25	0.508	0.508	0.020	42	0.102	*	0.0040
9	3.658	3.759	0.148	26	0.457	0.457	0.018	43	0.091	*	0.0036
10	3.251	3.404	0.134	27	0.417	0.406	0.016	44	0.081	*	0.0032
11	2.946	3.048	0.120	28	0.376	0.356	0.014	45	0.071	*	0.0028
12	2.642	2.769	0.109	29	0.345	0.330	0.013	46	0.061	*	0.0024
13	2.337	2.413	0.095	30	0.315	0.305	0.012	47	0.051	*	0.0020
14	2.032	2.108	0.083	31	0.295	0.254	0.010	48	0.041	*	0.0016
15	1.829	1.829	0.072	32	0.274	0.229	0.009	49	0.031	*	0.0012
16	1.626	1.651	0.065	33	0.254	0.203	0.008	50	0.025	*	0.0010

physical properties of annealed stainless steel soft wire

Annealed Stainless Steel Soft Wire

FEEDBACK FROM CONTACT WITH US

RELATED PRODUCTS

304 316 316L stainless steel wire rope

stainless steel wire mesh

stainless steel welding wire

Stainless Steel Tiny Wire

Stainless steel spring wire

Cold Drawn Stainless Steel Bright Wire

Stainless Steel Wire Rod

Material	Chemical composition
Grade	C	Si	Mn	P	S	Ni	Cr	Cu	Mo	Other
201	0.15	1	5.5-7.5	0.06	0.03	3.5-5.5	16-18			N<0.25
130M/202	0.15	1	7.5-10	0.06	0.03	4.00-6.00	17.0-19.0			N=0.25
301	0.15	1	2	0.45	0.03	6.0-8.0	16.0-18.0
302	0.15	1	2	0.45	0.03	8.0-10.0	17-19
302HQ	0.08	1	2	0.45	0.03	8.5-10.5	17-19	3.0-4.0
303	0.15	1	2	0.2	=0.15	8.0-10.0	17-19		=6.0
303Cu	0.15	1	3	0.2	=0.15	8.0-10.0	17-19	1.5-3.5	=6.0
304	0.08	1	2	0.045	0.03	8.0-10.0	18-20
304H	0.08	1	2	0.045	0.03	8.0-10.0	17-19
304HC	0.08	1	2	0.045	0.03	8.0-10.0	17-19	2.0-3.0
304HCM	0.08	1	2	0.045	0.03	8.0-10.0	17-19	2.5-4.0
304L	0.03	1	2	0.045	0.03	9.0-13.0	18-20
304M	0.06	1	2	0.045	0.03	8.9-10.0	18-20
304N1	0.08	1	2	0.045	0.03	7-10.5	18-20			N0.1-0.25
305	0.12	1	2	0.045	0.03	10.5-13	17-19
305J1	0.08	1	2	0.045	0.03	11-13.5	16.5-19
309S	0.08	1	2	0.045	0.03	12.0-15.0	22-24
301S	0.08	1.5	2	0.045	0.03	19-22	24-26
314	0.25	1.5-3	2	0.04	0.03	19-22	23-26
316	0.08	1	2	0.045	0.03	10.0-14.0	16-18		2.0-3.0
316Cu	0.03	1	2	0.045	0.03	10.0-14.0	16-18	2.0-3.0	2.0-3.0
316L	0.03	1	2	0.045	0.03	12.0-15.0	16-18		2.0-3.0
321	0.08	1	2	0.045	0.03	9.0-13.0	17-19			Ti=5
410	0.015	1	1	0.04	0.03		11.5-13.5
416	0.15	1	1.25	0.06	=0.15		12.0-14.0
420	0.26-4	1	1	0.04	0.03		12.0-14.0
410L	0.03	1	1	0.04	0.03		11.5-13.5
430	0.12	0.75	1	0.04	0.03		16-18
430F	0.12	1	1.25	0.06	0.15		16-18
631(ji)	0.09	1	1	0.04	0.03	6.5-8.5	16-18			AL0.75-1.5

Material	Chemical composition
Grade	C	Si	Mn	P	S	Ni	Cr	Cu	Mo	Other
201	0.15	1	5.5-7.5	0.06	0.03	3.5-5.5	16-18			N<0.25
130M/202	0.15	1	7.5-10	0.06	0.03	4.00-6.00	17.0-19.0			N=0.25
301	0.15	1	2	0.45	0.03	6.0-8.0	16.0-18.0
302	0.15	1	2	0.45	0.03	8.0-10.0	17-19
302HQ	0.08	1	2	0.45	0.03	8.5-10.5	17-19	3.0-4.0
303	0.15	1	2	0.2	=0.15	8.0-10.0	17-19		=6.0
303Cu	0.15	1	3	0.2	=0.15	8.0-10.0	17-19	1.5-3.5	=6.0
304	0.08	1	2	0.045	0.03	8.0-10.0	18-20
304H	0.08	1	2	0.045	0.03	8.0-10.0	17-19
304HC	0.08	1	2	0.045	0.03	8.0-10.0	17-19	2.0-3.0
304HCM	0.08	1	2	0.045	0.03	8.0-10.0	17-19	2.5-4.0
304L	0.03	1	2	0.045	0.03	9.0-13.0	18-20
304M	0.06	1	2	0.045	0.03	8.9-10.0	18-20
304N1	0.08	1	2	0.045	0.03	7-10.5	18-20			N0.1-0.25
305	0.12	1	2	0.045	0.03	10.5-13	17-19
305J1	0.08	1	2	0.045	0.03	11-13.5	16.5-19
309S	0.08	1	2	0.045	0.03	12.0-15.0	22-24
301S	0.08	1.5	2	0.045	0.03	19-22	24-26
314	0.25	1.5-3	2	0.04	0.03	19-22	23-26
316	0.08	1	2	0.045	0.03	10.0-14.0	16-18		2.0-3.0
316Cu	0.03	1	2	0.045	0.03	10.0-14.0	16-18	2.0-3.0	2.0-3.0
316L	0.03	1	2	0.045	0.03	12.0-15.0	16-18		2.0-3.0
321	0.08	1	2	0.045	0.03	9.0-13.0	17-19			Ti=5
410	0.015	1	1	0.04	0.03		11.5-13.5
416	0.15	1	1.25	0.06	=0.15		12.0-14.0
420	0.26-4	1	1	0.04	0.03		12.0-14.0
410L	0.03	1	1	0.04	0.03		11.5-13.5
430	0.12	0.75	1	0.04	0.03		16-18
430F	0.12	1	1.25	0.06	0.15		16-18
631(ji)	0.09	1	1	0.04	0.03	6.5-8.5	16-18			AL0.75-1.5
