Alloy 75 (UNS N06075, Nimonic 75) is a 80/20 nickel-chromium alloy with controlled additions of titanium and carbon. Nimonic 75 has good mechanical properties and oxidation resistance at high temperatures. Alloy 75 is most commonly used for sheet metal fabrications which require oxidation and scaling resistance together with medium strength at high operating temperatures. Alloy 75 (Nimonic 75) is also used in gas turbine engines, for components of industrial furnaces, for heat treating equipment and fixtures, and in nuclear engineering.
Chemical Composition:
Chemical Composition Limits | ||||||||
Weight% | Ni | Cr | Ti | C | Si | Cu | Fe | Mn |
Alloy 75 | Bal | 18.9 - 21.0 | 0.2 / 0.6 | 0.08 / 0.15 | 1.0 max | 0.5 max | 5.0 max | 1.0 max |
Mechanical Properties:
Properties | Metric | Imperial |
Tensile strength(annealed) | 750 MPa | 109 ksi |
Yield strength(annealed) | 275 MPa | 40 ksi |
Elongation at Break | 42% | 42% |
Modulus of Elasticity | 206 GPa | 29878 ksi |
Standard of execution:
Form | ASTM |
Rod | B 574 |
Plate, sheet and strip | B 575 |
Seamless pipe and tube | B 622 |
Welded pipe | B 619, B 775 |
Welded tube | B 626, B 751 |
Welding fitting | B 366 |
Forged or rolled pipe flange and forged fitting | B 462 |
Billet and bar for reforging | B 472 |
Forging | B 564 |
