Home » Products » Coil Sheet Strips » Sheet Plate » 304 Stainless Steel Sheet Plate
Share to:

304 Stainless Steel Sheet Plate

Standard: ASTM, AISI, JIS, GB ,SUS
Thickness: 0.2mm~150mm
Width: 40-2000mm or as your requirement
Length: 2000-11000mm or as your requirement
Technique: hot rolled: 3~150mm thickness
cold rolled: 0.2~6mm thickness

Standard: ASTM, AISI,  JIS, GB ,SUS
Thickness: 0.2mm~150mm
Width: 40-2000mm or as your requirement
Length: 2000-11000mm or as your requirement
Technique: hot rolled: 3~150mm thickness
cold rolled: 0.2~6mm thickness



ASTM A240(Chromium and Chromium-Nickel Stainless Steel Plate,Sheet, and Strip for Pressure essels and for General Applications)

304

C

Mn

P

S

Si

Cr

Ni

N

WT,%

≤0.07

≤2.00

≤0.045

≤0.030

≤0.75

17.5–19.5

8.0–10.5

≤0.10


JIS G4305(cold-rolled stainless steel plate, sheet and strip)

SUS 304

C

Mn

P

S

Si

Cr

Ni

WT,%

≤0.08

≤2.00

≤0.045

≤0.030

≤1.00

18.0–20.0

8.0-10.5


Mechanical Properties

Hardness, Brinell

123

123

Converted from Rockwell B hardness.

Hardness, Knoop

138

138

Converted from Rockwell B hardness.

Hardness, Rockwell B

70

70


Hardness, Vickers

129

129

Converted from Rockwell B hardness.

Tensile Strength, Ultimate

505 MPa

73200 psi


Tensile Strength, Yield

215 MPa

31200 psi

at 0.2% offset

Elongation at Break

70 %

70 %

in 50 mm

Modulus of Elasticity

193 - 200 GPa

28000 - 29000 ksi


Poisson's Ratio

0.29

0.29


Charpy Impact

325 J

240 ft-lb


Shear Modulus

86 GPa

12500 ksi



2B

The surface brightness and flatness of 2B is better than 2D then theough a special
surface treatment to improve its mechanical properties,2B could nearly Satisfy
comprehensive uses

No.3

Polished with abrasive belt of git#100#200#,have better brightness with
discontinuous coarse stria used as inner and external omaments for building,
electrical appliances and kitchen utensils etc.

No.4

Polished with abrasive belt of grit#150#180,have better brightness with
discontinuous coarse stria, but thinner than NO.3, are used as bathtub
buildings inner and extemal omaments electrical appliances kitchen
utensils and food processing

BA

Cold rolled, bright annealed and skin-passed, the product have
excellent brightness and food reflexivity like mirrorm kitchen
apparatus, omament etc.

8K

The product have excellent brightness and prefer reflexivity can
be the mirror.

HL

Polished with abrasive belt of trit#150#320 on the NO.4 finish and has
continuous streaks, mainly used as buildings omaments elevators,
door of building, frontal plate etc.



All our products are packed, stored, transported according to the international regulation. The products are wrapped with anti-rust paper and steel rings to prevent damage. Identification labels are tagged according to standard specification or customer's instructions. Special packing is available as per customer's requirement.Ply wooden box are available for special protection. Other kinds of packing can be offered if request.
